| PRICE LIST
TVS Apache 200
|
TYPE |
HARGA |
|
APACHE 200 |
24.500.000 |
| SPESIFIKASI
|
Type |
SI, 4 stroke, Oil cooled, Fi |
|
Displacement |
197.75 cm3 |
|
Maximum power |
Sport : 15.32 kW @ 9000 rpm (20.82 PS) | Urban/ Rain : 12.74 kW @7800 rpm (17.32 PS) |
|
Maximum torque |
Sport Mode : 17.25 Nm @ 7250 rpm | Urban/ Rain Mode : 16.51 Nm @5750 rpm |
|
Bore |
66 mm |
|
Stroke |
57.8 mm |
|
Bore to Stroke Ratio |
1.14 |
|
Fuel supply system |
Fuel Injection: Bosch- Closed loop |
|
Number of Valves |
4 |
|
Starting |
Electric Start |
|
Idle Speed |
1550 ± 200 rpm |
|
Ignition |
Mapped ignition system |
|
Air Cleaner Type |
Viscous Paper Filter |
|
Compression Ratio |
10.0 :1 |
|
Power to Weight Ratio |
0.1kW/kg |
|
Clutch |
Wet multi plate- slipper clutch with 5 plate |
|
Cooling System |
Oil Cooler with Ram Air Assist |
|
Muffler |
Twin Pipe and Twin Barrel Design |
|
Max Speed |
Sports Mode: 127 Km/h | Urban / Rain Mode: 105 Km/h |
|
Frame |
Double Cradle Split Synchro Stiff Frame |
|
Battery rating (Ah) |
12V, 8Ah VRLA |
|
Front Suspension |
Telescopic Forks with Preload Adjuster |
|
Rear Suspension |
Mono Tube – Mono Shock |
|
Brake and Clutch Levers |
Adjustable with 3 step position |
|
Headlamp* |
AHO LED Headlamp with LED position lamp |
|
Tail Lamp |
LED 2.5 W |
|
Gearbox |
5 Speed Gearbox |
|
Tyre (front) |
TVS 90/90-17 49P Tubeless |
|
Tyre (rear) |
TVS Eurogrip 130/70 R17 M/C 62P Tubeless (Radial) |
|
ABS |
Dual-Channel ABS with RLP Control | Single Channel Super-Moto ABS* |
|
Brake Fluid |
DOT 3 / DOT 4 |
|
Front |
Disc 270 mm (Petal Type) |
|
Rear |
Disc 240 mm (Petal Type) |
|
Wheel Rim |
Front: 1.85 x 17 (Alloy) | Rear: 3.50 x 17 (Alloy) |
|
Fuel Tank Capacity |
12 L |
|
Ground Clearance |
180 mm |
|
Height |
1050 mm |
|
Length |
2020 mm (Without Mud Flap) | 2050 mm (With Mud Flap) |
|
Width |
790 mm |
|
Kerb weight |
152kg |
|
Reserve |
2.5 L |
|
Saddle Height |
800 mm |
|
Wheelbase |
1353 mm |
*Keterangan: Spesifikasi yang ditampilkan merupakan unit dengan tipe tertinggi.
untuk informasi lebih lanjut mengenai tipe lainnya, Anda dapat menghubungi kontak yang tersedia pada website ini.
